SMEs review an EU-revised Standardization

Submitted by SBS

In November 2021, CEN TC10 (European Committee for Electrotechnical Standardization Technical Committee [TC]) — lifts, escalators and moving walks — received from the EU Commission (EC) the draft of a “New Standardization Request” concerning the revision of harmonized standards for lifts. The previous Standardization Request was issued in September 2016. The provisional revised standards developed by the TC did not prove to be fully aligned with the indications given in that request. These standards were also not aligned with various suggestions and comments, also by the EC desk officers, when being submitted for evaluation by CEN.

The draft of the new standardization request is thus welcomed by the small and medium-sized companies (SMEs) in the sector and their representatives. The request better defines in a legally binding document most of the issues that did not seem to be properly addressed during the initial revision work in the standardization committees.

It is now clearly specifying the objective of all the aspects of many Essential Health and Safety Requirements (EHSR) of the Lift Directive 2014/33/EC (LD) and of those of the Machinery Directive 2006/42/CE (MD) relevant for lifts.

Some items that were often overlooked are now clearly highlighted, as well. Among others, it is important to fully understand and mention the expected correct implementation of EHSR 1.1.2. of the MD (principles of safety integration) and EHSRs 1.6.1, 1.6.2, 4.4, 4.5, 6.1 and 6.2 of the LD, all of which, as can be inferred, are crucial for the smooth running of the sector.

In particular, the request highlights the need to improve the following aspects for all standards:

The provisions for the “foreseeable misuse” of the lift, in addition to its “intended use,” as indicated in EHSR 1.1.2. of the MD. It is evident that the “foreseeable misuse” is, too often, completely ignored. This could cause harm, damage or other consequences that should have been adequately addressed and prevented by appropriate additional provisions or dedicated features.

The provision of a complete set of instructions for the correct operation of the lift for its whole life-cycle, as indicated in EHSRs 6.1 and 6.2 of LD. To provide all the details for the “periodic checks,” considered necessary by the installers and manufacturers, under their responsibility, in order to guarantee a reliable and efficient set of “planned maintenance interventions.” They have to be clearly specified in a sort of “maintenance masterplan,” considering the effective course of operations of the specific lift: including timely settings, adjustments and also replacement of warn components. The Masterplan, together with the “logbook,” shall remain available at the lift site in a position easily identifiable and accessible to the maintenance and rescue operators.

In addition, for specific standards, further requirements are:

For “accessibility,” an adequate implementation of the United Nations Convention on the Rights of Persons with Disabilities should be carried out addressing also some of the specific needs of persons with disabilities, and not be limited to only standards EN 81-70 and EN 81-76. It is now requested that other standards for lifts (such as EN 81-20, EN 81-21 and EN 81-22) shall also include provisions covering different aspects of accessibility of lifts based on the “Design-for-All approach,” as indicated in EHSRs 1.6.1 and 1.6.2 of the LD. The objective is to ensure barrier-free and easy access and use of lifts to all users, by applying functional requirements that consider the various sensory abilities of users, including those with disabilities, and the way in which persons with different types of disability can interact with the lift.

For the “two-way means of communication”, it is also required the implementation of the “Design-for-all approach” in the standard EN 81-28. It must be noted that the application of those functional requirements that take into account various types and levels of sensory abilities would require more sophisticated features for both the device in the lift car and the connected one in the relevant call center.

The roadmap of this draft standardization request includes some discussions between the EC and CEN for the agreement on the various details, in addition to consultation of other stakeholder organizations, such as Small Business Standards (SBS), in line with EU rules. Among some of the parties involved, there is the awareness that there may be a strong resistance within CEN to accept some of the above-mentioned issues that are extremely important for lift SMEs, and so have to be fully supported and urgently implemented.

In fact, it is already known in the lift sector that all such above-mentioned issues are already fully implemented in other parts of the world, specifically in the North American markets — some of them since very recently, others more than 20 years ago.

The lift sector and its SMEs should be confident that the EC and the CEN representatives, appropriately setting aside corporate interests, manage to find the only acceptable agreement capable of bringing our European standards for lifts to the state of the art nowadays recognized in the most developed countries of the world. This would be the only way to confirm the leadership of Europe in the support of “Free Competition” and of “the Citizens’ Rights,” so often mentioned.

SBS and EFESME, working together for many years to protect European SMEs in the lift industry, will continue to follow this topic with interest and attention and intervene in the appropriate and necessary manner. We will keep all readers informed about any further development of this “New Standardization Request.” For more information, contact SBS.
